API Spec 12P

This specification covers material, design, fabrication, and testing requirements for fiberglass reinforced plastic (FRP) tanks. Only shop fabricated, vertical, cylindrical tanks are covered. Tanks covered by this specification are intended for above ground and atmospheric pressure service. This specification applies to new tanks. The requirements may be applied to existing tanks at the discretion of the owner/operator.

This specification is designed to provide the petroleum industry with various standard sizes of FRP tanks. Because of the versatility of FRP tanks, the user shall be responsible for determining the suitability of FRP tanks for the intended service.

Unsupported cone bottom tanks are outside the scope of this specification.

Product Details

Edition:
5th
Published:
05/01/2022
Number of Pages:
30
File Size:
1 file , 1.3 MB
Product Code(s):
G12P05, G12P05, G12P05
Note:
This product is unavailable in Russia, Cuba, Syria, North Korea, Ukraine, Belarus, Iran
API Spec 12P

This specification covers material, design, fabrication, and testing requirements for fiberglass reinforced plastic (FRP) tanks. Only shop-fabricated, vertical, cylindrical tanks are covered. Tanks covered by this specification are intended for above ground and atmospheric pressure service at various sizes and capacities ranging from 90 to 1500 barrels. Unsupported cone bottom tanks are outside the scope of this specification.

Standard designs are based on a maximum working pressure equal to the hydrostatic head of the stored fluid plus 6 in. of water column (0.217 psig) and 2 in. of water column vacuum. Design criteria are dependent on method of construction. Filament winding, chop-spray and combinations of these methods (commonly referred to as chop-hoop) are covered. Tanks constructed using hand lay-up (contact molding) are to be designed to the same standard as chop-spray construction.

Product Details

Edition:
3rd
Published:
10/01/2008
Number of Pages:
27
File Size:
1 file , 860 KB
Product Code(s):
G12P03, G12P03, G12P03
Note:
This product is unavailable in Cuba, Iran, North Korea, Syria
API Spec 12P

This specification covers material, design, fabrication, and testing requirements for fiberglass-reinforced plastic (FRP) tanks. Only shop-fabricated, vertical, cylindrical tanks are covered. Tanks covered by this specification are intended for aboveground and atmospheric pressure service. Unsupported cone bottom tanks are outside the scope of this specification.

This specification is designed to provide the petroleum industry with various standard sizes of FRP tanks. Because of the versatility of FRP tanks, the user shall be responsible for determining the suitability of FRP tanks for the intended service.

This specification applies to new tanks. The requirements may be applied to existing tanks at the discretion of the owner/operator.

Product Details

Edition:
4th
Published:
02/01/2016
Number of Pages:
27
File Size:
1 file , 580 KB
Redline File Size:
2 files , 4.3 MB
Product Code(s):
G12P04, G12P04, G12P04
Note:
This product is unavailable in Cuba, Iran, North Korea, Syria
API Spec 12P

Covers minimum requirements for material, design, fabrication, and testing of fiberglass reinforced plastic tanks.

Product Details

Edition:
2nd
Published:
01/01/1995
ANSI:
ANSI Approved
Number of Pages:
19
File Size:
1 file , 1.7 MB
Product Code(s):
G12P02, G12P02, G12P02
Note:
This product is unavailable in Cuba, Iran, North Korea, Syria
